Horizontal Pulse Vacuum Autoclave, Motor Hinge Door

Horizontal Pulse Vacuum Autoclave Feature:

The sliding door features a detachable gear-meshing seal, motor-chain driven for vertical movement.
It has a double-door passage with interlocking doors and pressure-temperature safety interlocks for liquid programs.
Automatic sealing is achieved with an inflatable, tear-resistant silicone ring, offering durability up to 1500 cycles.
The rectangular body has a European-style ribbed sleeve structure with welded sealing grooves for enhanced stability.

Horizontal Pulse Vacuum Autoclave Specification:

Model	ST-BA650PV	ST-BA800PV	ST-BA1000PV	ST-BA1200PV	ST-BA1500PV
Chamber Size (ØxL) mm	610×910×1200	610×910×1500	610×910×1800	680×1180×1500	680×1180×1850
Volume(L)	650	800	1000	1200	1500
Overall Sizes (WxDxH)(mm)	1500×1350×1900	1800×1350×1900	2100×1350×1900	1800×1420×2000	2100×1420×2000
Weight (kg)	1250	1350	1550	1650	1850
Steam Consumption (KG/C)	35	47	55	65	80
Water Consumption (KG)	320	400	500	600	750
Power	380V, 50Hz, 3KW+(36KW)	380V, 50Hz 3.5KW+(48KW)	380V, 50Hz 3.5KW+(54KW)	380V, 50Hz 3.5KW+(72KW)	380V, 50Hz, 4KW+(90KW)
N.W. (kg)		1350	1550	1650	1850
Chamber Design Pressure	0.3MPa
Generator Design Pressure	1.0MPa
Design Temperaure	150℃
Maximum Operating Temperature	139℃
Maximum Operating Pressure	0.25MPa
Chamber Relief Valve	0.28MPa
Jacket Relief Valve	0.28MPa
Accuracy of Pressure	0.1KPa
Sterilization Temperature Control Accuracy	±1℃
Temperature Uniformity	±1℃
Negative Pressure Pulsating Vacuum	-80~0KPa
Across the Pressure Pulsation	-80~80KPa
Positive Pressure Pulse	0~9 times
Maximum Vacuum	-96KPa
