Adopting multi-layer serpentine glass condenser tubes to ensure high recovery rate.
Advantage:
Specification:
| Model | RE-301R | RE-501R | |
| Rotating Flask | Capacity | 3 L | 5 L |
| Caliber | 50# flange port | ||
| Receiving Flask | Capacity | 2 L | 3 L |
| Caliber | 35# spherical ground joint | ||
| Feeding Switch | 19# standard ground joint，9mm barb fitting | ||
| Condenser | Vertical coiled tube | Vertical coiled tube with spherical ground joint | |
| Condenser Size (Dia.×H)(mm) | 90×430 | 97×460 | |
| Condensation Area (㎡) | ≈0.2 | ≈0.27 | |
| Condenser Circulation Connection Port | 11 mm OD barb fitting | ||
| Seal | Teflon and fluororubber combination double seal | ||
| Temperature Control Accuracy | ±1℃ | ||
| Rotational Speed (rpm) | 0–120 | 0–90 | |
| Screen Display | Temperature and speed digital display | ||
| Temperature Control | Button | ||
| Speed Control | Knob | ||
| Motor Power | 40 W | ||
| Lifting Method | Manual lifting | ||
| Lifting Travel Range (mm) | ≈0–140 | ≈0–120 | |
| Maximum Evaporation Capacity (Water) (L/h) | About 1.5 | About 2 | |
| Vacuum Degree | -0.098 Mpa | ||
| Power Supply | 220 V, 50 Hz | ||
| Temperature Control Range | Water bath, RT to 99 ℃; oil bath, RT to 180 ℃ | ||
| Bath Pot | Inner Liner Material | 304 stainless steel | |
| Inner Liner Size (Dia.×H) | 280×170 mm | ||
| Capacity | 5 L | ||
| Heating Power | 1.5 kW | ||
| Size (D×W×H) | 360×330×260 mm | ||
| Size (D×W×H)(mm) | ≈670×340×960 | ≈900×430×1100 | |
| Shipping Size (D×W×H)(mm) | 710×560×660 | ||
| G.W. (kg) | 28 | 30 | |
| Recommended Equipment (excluding) | Circulating water vacuum pump VP-DIIIS and low-temperature coolant circulation pump LTC-530 | ||
