| Storage Capacity |
25L |
25L |
25L |
2L |
| Cooling Engine |
Free Piston Stirling Cooler |
| Refrigerant |
Helium (He) |
| Heat Transport System |
Gravity Driven Thermosiphon |
Direct Cooling |
| Temperature Range |
18℃ to -45℃ |
18℃ to -60℃ |
18℃ to -86℃ |
18℃ to -86℃ |
| Performance Data |
Take 1.5 hours from 25℃ to -45℃ |
Take 2.5 hours from 25℃ to -60℃ |
Take 3.5 hours from 25℃ to -80℃ |
Take 2 hours from 25℃ to -120℃ |
| Ambient temperature is 25°C; Empty Cabinet |
| Environmental Condition |
Non-corrosive, Non-flammable, Non-explosive, Altitude up to 2000m (Temperature 5°C to 35°C, maximum relative humidity 80%) |
| Temperature Control Capability |
Target temperature ±1°C |
Target temperature ±1°C |
Target temperature ±2°C |
Target temperature ±1°C |
| Stable State Energy Consumption |
30W |
40W |
75W |
70W |
| Ambient temperature is 25°C |
| Insulation |
High performance vacuum insulated panels, polyurethane foam |
High performance polyurethane foam |
| Insulation Layer Inner Liner Material |
Food-grade sus304 |
| Noise |
＜50dB |
＜55dB |
| Control Sensor |
One RTD(PT100 Class B), precision±0.3 |
| Security |
Lockable Lid |
| Warm and Cold Alarms |
Setpoint ±10°C |
| Defrost Method |
Manual |
| Electric Power |
100V AC to 240V AC; 50Hz, 60Hz; 12V DC to 24V DC |
| Internal Size (W×D×H)(mm) |
300×250×300 |
160×160×80 |
| External Size (W×D×H)(mm) |
616×392×455 |
245×246×450 |
| Shipping Size (W×D×H)(mm) |
710×480×530 |
390×400×550 |
| N.W./G.W. (kg) |
17.5/21 |
11/16 |
