Multi-view Microscope Feature:

Dual viewing heads support multiple users and simultaneous observations.
360° rotatable heads allow flexible angle adjustments for comfortable viewing.
Advanced infinite optics deliver clear and precise imaging.
Wide field of view enhances sample detail capture.
4X, 10X, 40X, 100X infinite plan achromatic objectives offer versatile magnification.
Precision focusing ensures sharp and clear observations.

Multi-view Microscope Specification:

Model	MSC-MV510T
View Head	Siedentopf trinocular head, Inclined at 30°, 360° Ratatable, Interpupilary distance 48-75mm (1pc, main microscope)
View Head	Siedentopf binocular head, Inclined at 30°, 360° Ratatable, Interpupilary distance 48-75mm (4pcs, secondary microscope)
Optical System	Infinite optical system
Eyepiece	Extra wide field evepiece WF10X/20
Objective	Infinite plan achromatic objective 4X, 10X, 40X, 100X
Nosepiece	Inverse quintuple nosepiece
Condenser	Swing condenser NA.0.9/0.25
Focusing	Coaxial coarse & Fine focus adjustment, Fine division 0.002mm
Stage	Double layers mechanical stage
	Stage Size: 185x142mm
	Moving Range: 75x55mm
lllumination	Kohler lllumination, External lllumination, Halogen Lamp 12V50W
Pointer	Green LED pointer, brightness adjustable
Photo Attachment	Optional
Video Adapter	C Mount 1 x (Optional);
Video Adapter	C Mount 0.5 x (Optional);
Power Supply	AC220/110V, 50/60Hz
Shipping Size (W×D×H)(mm)	500x420x700; 380x730x470
G.W. (kg)	16;17
