High precision mulifunctional solid and liquid densimeter is widely used and with full functions, suitable for the field of quality management, cost control, scientific academies, researching key laboratories. etc.
| Model | DME-120PSL | DME-300MSL | ||
| Capacity | 120 g | 300 g | ||
| Display | LCD | LCD | ||
| Density Resolution | 0.0001 g/cm3 | 0.001 g/cm3 | ||
| Weight Range | 0.001–120 g | 0.005–300 g | ||
| Density Range | 0.0001–99.9999 g/cm3 | 0.001–99.999 g/cm3 | ||
| Solid Mode | Measuring Solid Items | Density of all forms of solid, including metal, rubber, plastic, film, floating body,powder, foam, viscous body, structure, tubing, wood, sponge, glass, pitch, cement,soil, gem, paper, concrete, graphite, coal, rock, ceramic.etc. (cover the products of hygroscopicity, non-absorbency, high-viscosity) | ||
| Measuring Mode | Archimedes principle | |||
| A. general solid measuring method | ||||
| B. porosity materials saturation mode | ||||
| C. porosity materials surface covering method mode. | ||||
| D. professional constant volume mode method | ||||
| E. professional rubber abrasion loss and expansibility mode method | ||||
| F. professional hygroscopicity mode method | ||||
| G. professional oil length mode method | ||||
| Measurable Project | Density of general non-absorbency solid | |||
| Density of porosity materials | ||||
| Oil length of oil bearing | ||||
| Porosity of porosity materials | ||||
| DIN volume abrasion loss of rubber | ||||
| Powder density | ||||
| Water absorption rate | ||||
| Measuring Time | About 5 seconds | |||
| Memory Method | Memory in shorter time by one procedure | |||
| Specific Gravity Measurement Frame | Completed injection forming professional specific gravity measurement frame, Size (L×W×H): 13.5×5×11.6 mm | |||
| Measurement Tank | Completed injection forming transparent professional measurement tank, Size (L×W×H): 16.9×9.8×8.3 mm | |||
| Result Display | Display according to the model: density, specific gravity, apparent density, volume density, wet density, total porosity, effective porosity, oil content, ,water absorption, wear loss, wear index,expansibility,volume and so on. | |||
| Function Setting | Water temperature setting,density setting of medium of comparative solution, density setting of medium of water proofing treatment, bound setting,aerostatic buoyancy setting, loss value setting of fixed weight of reference glue,loss value setting of weight of reference glue,density setting of reference glue. | |||
| Mixed Material Percentage | Function introduction | Automatically read the percentage of the main material in the two kindsof mixed materials | ||
| Setting | Freely set the density value of main material and subordinate material | |||
| Display | Density value, percentage of main material | |||
| Liquid Mode | Measurement Type | a:Mobility liquid, vicidity liquid, volatile liquid, corrosivity liquid, high temperature liquid, suspension liquid, emulsion and so on. | ||
| b:Alcohol, scaling powder, essence, blood, sodium chloride, glycerol, electrolyte, diesel,refrigerating, hydrofluoric acid, dichloromethane, vitriol. | ||||
| Measurement Principle | Archimedes principle displacement method | |||
| Measurement Mode | 3 groups | |||
| Measurement Time | About 5 seconds | |||
| Memory Mode | Memory in shorter time by one procedure | |||
| Result Display | Density and baume | |||
| Specific Gravity Measurement Frame | Stainless steel specific gravity measurement frame | |||
| Function Setting | Temperature setting, density setting, measurement weights setting of standard sensor ball and weights setting in the water. | |||
| Measurement Testing | Distilled testing | |||
| Calibration | Auto correction with one button, auto detection. | |||
| Output Interface | RS-232 interface, output and print testing data conveniently | |||
| Standard Accessories | Tank, testing board, tweezers, thermometer, 100g weight, windproof and dustproof dust cover, 1 set of measuring floating body parts, power transformer, standard liquid measurement assembly. | |||
| Optional Accessories | Printer, anti-corrosive liquid measurement assembly | |||
| Power Supply | 220/110 V, 50/60 Hz | |||
| External Size (W×D×H) | 195×230×197 mm | |||
| Shipping Size (W×D×H) | 440×180×345 mm | |||
| N.W./G.W. (kg) | 1.6 / 4.5 | 1.8 / 4.5 | ||
