Hotplate Magnetic Stirrer, HMS-350P

HMS-350P supports stirring of up to 10 L solution with high-temperature resistant high-strength magnet.

Advantage:

7-inch ceramic-coated heating plate: 180 mm plate diameter, maximum temperature 350 ℃.
Brushless DC motor (BLDC): Lower noise and longer service life.
High-temperature resistant high-strength magnet: Supports stirring of up to 10 L solution.
Internal & external dual PT1000 sensors: Enables plate temperature control and direct solution temperature control.
Additional functions: Equipped with timing, forward/reverse rotation, locking, and other functions.

Speciﬁcation:

Model	HMS-350P
Work Plate Dimension	180×180 mm
Work Plate Material	Aluminum cover with ceramic coating
Motor Type	Brushless DC motor
Stirring Position	1
Max. Stirring Quantity [H₂O]	10 L
Speed Range	100–2000 rpm (forward/reverse rotation)
Control Accuracy of Sensor	±10 rpm
Speed Display	LED
Temperature Display	LED
Heating Temperature Range	Room temp. to 350 ℃
Over Heat Protection	380 ℃
Temperature Display Accuracy	1 ℃
External Temperature Sensor	PT1000 (accuracy ±0.5 ℃)
Timer	99 h 59 min 59 s (count-down timer/count-up timer)
Alarm Function	Alarm、lock
Motor Rating Output	20 W
Heating Output	800 W
Voltage	100–120/200–240 V, 50/60 Hz
Permissible Ambient Temperature and Humidity	5–40 ℃, 80% RH
Shipping Size (W×D×H)	355×310×150 mm
G.W	4.2 kg

Hotplate Magnetic Stirrer, HMS-350P
