| Capacity(L) | 255 | 360 | 600 | 800 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 | 6000 |
| Interior Design Pressure | -0.1~03MPa |
| Jacket Design Pressure | 0.3MPa |
| Design Temperature | 150℃ |
| Max Working Temperature | 139℃ |
| Max Working Pressure | 0.25MPa |
| Vacuum Leakage Rate | ≤0.13KPa/min |
| Final Vacuum | -96KPa |
| Opening Pressure of the Inner Chamber Safety Valve | 0.28MPa |
| Jacket Safety Valve Opening Pressure | 0.28MPa |
| Sterilization Temperature Control Precision | 0-2℃ |
| Temperature Uniformity | ±0.5℃ |
| Negative Pressure Pulsating Vacuum Negative Value and Number | Amplitude -80~0KPa, frequency 1~99 |
| Number of Pulsations Across Pressure | Amplitude -80~80KPa, frequency 1 |
| Number of Positive Pressure Pulsations | 1~3 |
| Inner Tank Size (WxH)(mm) | 550×550 | 610×610 | 610×910 | 610×910 | 610×910 | 680×1180 | 680×1180 | 900×1380 | 900×1380 | 900×1380 | 900×1380 | 900×1380 |
| Depth | 850 | 1000 | 1200 | 1500 | 1800 | 1500 | 1850 | 1620 | 2050 | 2400 | 3200 | 4800 |
| Overall Size (LxWxH)(mm) | 1150x1280x1800 | 1300x1350x1850 | 1500x1440x1900 | 1800x1440x1900 | 2100x1440x1900 | 1800x1480x2000 | 2100x1480x2000 | 1970x1750x2200 | 2350x1750x2200 | 2700x1750x2200 | 3500x1750x2200 | 5400x1750x2200 |
| Weight (kg) | 750 | 850 | 1250 | 1350 | 1550 | 1650 | 1850 | 2300 | 2700 | 3500 | 3500 | 6200 |
| Gas Consumption (Kg/c) | 18 | 22 | 35 | 47 | 55 | 65 | 80 | 106 | 132 | 132 | 132 | 132 |
| Water Consumption (Kg/c) | 120 | 180 | 320 | 400 | 500 | 600 | 750 | 1000 | 1250 | 1250 | 1250 | 1250 |
| Power Supply | 380V,50HZ | 380V,50HZ | 380V,50HZ | 380V,50HZ | 380V,50HZ | 380V,50HZ | 380V,50HZ | 380V,50HZ | 380V,50HZ | 380V,50HZ | 380V,50HZ | 380V,50HZ |
| Consumption | 2KW+(24KW) | 2KW+(30KW) | 3KW+(48KW) | 3.5KW+(54KW) | 3.5KW | 3.5KW | 4KW | 4.5KW | 6KW | 8KW | 8KW | 12KW |
