Fully Automatic Tissue Slide Stainer, Large Capacity

This fully automated tissue slide stainer is suitable for use where large volumes of tissue specimens need to be processed, such as clinical diagnostic centres or biomedical research facilities.

Model: TS-I; TS-II
Number of processing chambers: 14; 18
Capacity of each chamber : 1500 mL; 750 mL
Processing time per station: 0-59 min 59 sec (adjustable)
Number of slides processed simultaneously: 70 pcs; 50 pcs

Share the product

Application:

Automated slide stainers are primarily used as biomedical tools, typically in medical laboratories. This automatic slide stainer provides staining flexibility for staining up to hundreds of slides simultaneously. Suitable for use in histopathology, haematology and cytopathology studies, it is the ideal tool to facilitate the preparation of slides for diagnostic and research purposes.

Advantage:

7-inch intelligent touch color screen for real-time display of working status, with clear and intuitive visualization.
Supports dye name entry and viewing, along with real-time status monitoring for more intuitive data presentation.(Only for TS-II)
Synchronous display of working stations enables clear and convenient progress tracking.
Intelligent hot air control for automatic drying.
Imported solenoid valves with intelligent control enable fully automatic water intake and drainage for thorough cleaning.
Built-in circulating air purification system, efficiently absorbs harmful gases.(Only for TS-I)

Speciﬁcation:

Model	TS-I	TS-II
Number of Processing chambers	14 (1 for rinsing, 1 for drying)	18 (1 for rinsing, 1 for drying)
Single Chamber Capacity	1500 mL	750 mL
Processing Time per Station	0-59 min 59 sec (adjustable)
Dripping Time	adjustable within 0-30 s
Temporary Rinse Time	0~59 seconds
Number of Slides Processed Simultaneously	70 pcs	50 pcs
Programmable	20 sets
Programmable Immersion Sequence	1-28	1-36
Power Supply	AC100 V – 120 V / AC 220 V- 240 V 50 Hz / 60 Hz
Consumption	500 W
External Size (W×D×H)	1380×420×470 mm
N.W.	70 kg	75 kg
