Ductless Fume Hood Feature:

Real-time temperature and humidity monitoring with alarm settings for product safety.
Filter saturation alarm with dual VOC probes: one for air quality, the other for filter status.
Advanced filtering system adsorbs harmful gases, dust, and other substances based on experimental needs.
Provides API interfaces for third-party platform integration.
With Automatic Closed-Loop Airflow Velocity Control System.

Ductless Fume Hood Specification:

Model	FMH-800DL(II)	FMH-1000DL(II)	FMH-1200DL(II)	FMH-1600DL(II)
External Size (W×D×H) (mm)(Main Unit)	800×620×1100	1000×620×1100	1275×620×1100	1600×620×1100
External Size (W×D×H) (mm)(Base Cabinet)	800×600×690	1000×600×690	1200×600×690	1600×600×690
External Size (W×D×H) (mm)(Optional Base Stand)	__
Internal Size (W×D×H) (mm)	780×570×775	980×570×775	1180×570×775	1580×570×775
Airflow Velocity	0.4~0.6m/s
Airflow Volume	130m³/h	130m³/h	230m³/h	230m³/h
Blower	1pcs	1pcs	2pcs	2pcs
Blower	Imported PSC blower
Pre-Filter (mm)	1pcs (370×395×21)		2pcs (370×395×21)
Chemical Filter (Molecular Filter)	1 groups	1 groups	2 groups	2 groups
	OG: Organic filter
	AG: Inorganic filter
	AM: Ammonia gas filter
	FO: Formaldehyde filter
	HEPA H14: HEPA filter
	(Customer can choose any filter type according to the number of filters and the type of chemicals to operate.)
Display	7-inch LCD touch screen
Material	External: Galvanized steel sheet, diameter ≥1.5mm, Epoxy resin electrostatic spraying, corrosion resistance;
	Front and Side: ≥ 8mm acrylic board;
	Work Surface: Epoxy resin, corrosion resistance, high temperature resistance
Alarm Function	Filter saturation alarm; VOC alarm;Fan system failure alarm
Sound Emission	≤52dB(A)
Consumption	60W	60W	120W	120W
Power Supply	110V~240V, 50/60Hz
Standard Accessory	Base cabinet, Chemical filters, Pre-filter, LED lamp, LCD touch screen, PSC blower, Real time temperature environmental monitoring system; Air Velocity Sensor
N.W/G.W (Main Unit)	102kg/122kg	114kg/144kg	132kg/167kg	174kg/216kg
N.W/G.W (Base Cabinet)	54kg/69kg	62kg/82kg	90kg/115kg	114kg/142kg
N.W/G.W (Optional Base Stand)	__
Shipping Size (W×D×H)(mm)(Main Unit)	860×680×1450	1060×680×1450	1360×680×1450	1690×680×1450
Shipping Size (W×D×H)(mm)(Base Cabinet)	860×620×900	1060×620×900	1300×620×900	1660×620×900
Shipping Size (W×D×H)(mm)(Optional Base Stand)	__
