Cryo-Embedding Center, TE-V

Cryo-Embedding Center, TE-V

This fully automatic cryo-embedding center features large capacity and precise temperature control technology, as well as a memory function, which can help you complete tissue embedding efficiently and conveniently.

  • Model: TE-V
  • Paraffin Chamber Capacity: 6 L
  • Temperature Range (Forceps Holder, Left & Right Thermal Chamber, Paraffin Chamber & Distributor, Working Table): 0-99 ℃
  • Temperature Range (Cold Plate): RT to -30 ℃
  • Working Area Sizes (Working Table): 270×100 mm
  • Working Area Sizes (Cold Plate): 410×410 mm
  • Small Cooling Plate: YES

Share the product


Warning: call_user_func_array() expects parameter 1 to be a valid callback, function 'wpb_pcf_contact_form_button' not found or invalid function name in /www/wwwroot/www.scitekuae.com/wp-includes/class-wp-hook.php on line 341
Category: Tag:

Cryo-Embedding Center Feature:

  1. 7-inch touchscreen displays real-time temperatures for all functional modules.
  2. PID temperature control algorithm ensures ±0.1 °C accuracy.
  3. Live temperature curve visualization for intuitive monitoring.
  4. Rapid, uniform heating with independent zone control and dual overheat protection.
  5. Intelligent paraffin melting mode improves efficiency and control.
  6. Fully automated program control supports 24/7 operation with flexible scheduling.
  7. Memory and auto-recovery functions retain preset temperatures automatically.
  8. Dual paraffin dispensing via manual control or foot pedal.
  9. Adjustable paraffin flow rate and dispensing time.
  10. Shadowless illumination with adjustable brightness and timer.
  11. Modular split design enables flexible configuration of embedding unit and cold plate.
  12. Independent left/right thermal chambers with removable inner and outer boxes for easy maintenance.
  13. Large work surface with anti-overflow guide channels and beaker maintenance access.

Cryo-embedding Center Specification:

Model TE-V
Paraffin Chamber Capacity 6 L
Temperature Range Forceps Holder 0-99 ℃
Paraffin Chamber
Left Thermal Chamber
Right Thermal Chamber
Working Table
paraffin Distributor
Thermal System 30-90 ℃
Cold Plate RT to -30 ℃
Small Cooling Plate About 5 ℃
Temperature Control Precision ± 0.1 ℃
Paraffin Flow Control Manual and foot-operated dual control methods
Fully Programmable ON/OFF Control Allows automatic system start and stop anytime weekly
Safety Protection Double overheat protection device
Automatic Memory Recovery Function Yes
Working Area Size Thermal Chamber 240×160×50 mm
Working Table 270×100 mm
Small Cooling Plate 80×60 mm
Cold Plate 410×410 mm
Thermal System 310×316×55 mm
Power Supply AC 220 V±10% 50 Hz (standard model); AC 110 V±10% 60 Hz
Power 800 W（Tissue Embedding Center）
200 W (Cooling System)
500 W (Thermal System)
Dimensions Size (W×D×H) 650×647×465 mm (Tissue Embedding Center)
632×410×446 mm (Cooling System)
410×660×450 mm (Thermal System)
Shipping Size (W×D×H) 790×730×700 mm (Tissue Embedding Center)
810×540×630 mm (Cooling System)
730×530×620 mm (Thermal System)
N.W. /G.W. 26/50 kg (Tissue Embedding Center)
20/45 kg (Cooling System)
12/36 kg (Thermal System)
