- Model : IVC-BF700
- Capacity(L) : 500ml x 36
- Control System : PLC
- Bottle Filling : 36 units
- Water Pressure : 0.2-0.3MPa
- Size(W×D×H)(mm) : 900x800x915
Bottle Filling System
Bottle Filling System Application:
IVC-BF700 is designed for the automatic filling of water bottles used for experimental animals. It offers a streamlined process where the bottle rack insertion triggers an automatic water flow detection, ensuring both convenience and efficiency.
Bottle Filling System Specifications:
| Model | IVC-BF700 | ||
| Capacity(L) | 500ml x 36 | ||
| Control System | PLC | ||
| Display | 4.3 inch LCD touch screen | ||
| Bottle Filling | 36 units | ||
| Water Pressure | 0.2-0.3MPa | ||
| Water Inlet Pipe | Quantity | 1 | |
| Length | 2m | ||
| Material | Food grade silicone tube | ||
| Water Outlet Pipe | Quantity | 1 | |
| Length | 2m | ||
| Material | PE | ||
| Structure | Material | External | 304 stainless steel |
| Internal | 304 stainless steel | ||
| Caster | Four universal casters at the bottom of the instrument for easy movement | ||
| Total Consumption | 300W | ||
| Power Supply | 380V, 50/60Hz | ||
| External Size(WxDxH)(mm) | 900x800x915 | ||
| Shipping Size(WxDxH)(mm) | 1050x970x1160 | ||
| N.W./G.W. (kg) | 70/90 | ||
- PLC control system with a 4.3-inch full-color touchscreen for intuitive display and control.
- Includes an emergency stop switch and control switch for easy operation.
- Highly automated with automatic bottle rack insertion detection and adjustable filling volume within the program.
- Automatic pipeline disinfection for added convenience and hygiene.
