| External Size(W×D×H)(mm) | 1540×880×2000 | 1790×880×2080 |
| Internal Size(W×D×H)(mm) | 910×650×660 | 1165×650×660 |
| Pass Box | External Size (W×D×H)(mm) | 575×425×495 |
| Internal Size (W×D×H)(mm) | 430×330×355 |
| Control System | Display | LCD display |
| Alarm | Audio and Visual alarm, including abnormal pressure and filter replacement |
| Air Filtration System | Pre-Filter | Polyester fiber,washable (Negative pressure ≥120 Pa) |
| ULPA Filter | Total 3pcs,efficiency ≥99.9995% at 0.12μm |
| Air supply filter |
| First exhaust filter |
| Second exhaust filter |
| Cleanliness Grade | Class 100 (ISO14644.1 Class 5) |
| Cabinet Construction | Main Body | Electro-galvanized steel with antimicrobial Powder Coating |
| Work Surface | 304 stainless steel |
| Front Window | 8mm toughened glass,anti-ultraviolet radiation |
| Gloves | One pair of 800mm butyl rubber gloves |
| Electrical System | UV Lamp | 18W×2, 8W×1 | 30W×2, 8W×1 |
| Emission of 253.7 nanometers for most efficient decontamination |
| LED Lamp | 12W×2 | 16W×2 |
| Max.Consumption | 1200W | 1300W |
| Power Supply | AC220V±10%, 50/60HZ; 110V±10%, 60Hz |
| Illumination | ≥1000 Lux |
| Sound Emission | ≤67dB(A) |
| Standard Accessory | 1.Gloves; 2.LED Lamp×2; 3.UV Lamp×3; 4.Pressure Meter; 5.Drain Valve; 6.ULPA Filters; 7.Footmaster Caster; 8.Waterproof Socket×2 |
| Gross Weight | 350kg | 450kg |
| Shipping Size (W×D×H)(mm) | 1635×1065×2160 | 1890×1065×2250 |
| Shipping Volume | 3.8m³ | 4.5m³ |
