- Model : MSC-BH102B; MSC-BS102B
- Viewing Head : Seidentopf Binocular Head lnclined at 45°interpupillary (55-75mm) / Sliding Binocular Head inclined at 45°interpupillary (55-75mm)
- Eyepiece : Wide Field Eyepiece WF10x18mm
- Objective : Achromatic Objective 4x, 10x, 40x, 100x
Biological Microscope with Double Layers Mechanical Stage
Biological Microscope Feature:
- LCD Display System:
Equipped with a 7-inch high-definition screen, this microscope supports multiple magnifications and 16:9 or 4:3 display modes. With a 1024×600 resolution, it delivers clear, detailed images. - Digital Display & Storage System:
Featuring a 10-inch display and an 8.0M HDMI camera, the microscope supports 720P@60fps HDMI output and 3840×2160 photo resolution. A remote control allows easy operation and storage management.
Biological Microscope Specification:
| Model | MSC-BH102B | MSC-BS102B |
| Viewing Head | Siedentopf Binocular Head | Sliding Binocular Head |
| lnclined at 45° Interpupillary (55-75mm) | Inclined at 45° Interpupillary (55-75mm) | |
| Eyepiece | Wide Field Eyepiece WF10x18mm | |
| Nosepiece | Quadruple Nosepiece | |
| Objective | Achromatic Objective 4X, 10X, 40X, 100X | |
| Stage | Double Layers Mechanical Stage 115x125mm/70x30mm | |
| Condense | Abbe NA1.2５ with Iris Diaphragm & Filter | |
| Focusing System | Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Fine Stroke 0.2mm per Rotation, Moving Range 20mm | |
| Illumination | LED Illumination, Brightness Adjustable | |
| Halogen Lamp 100V-240V/ 6V20W | ||
| Plan-concave Mirror | ||
| Package | Styrofoam | |
| Carton | ||
| Wooden Case | ||
| Shipping Size(W×D×H)(mm) | 350x240x480 | |
| G.W. (kg) | 6 | |
