| Capacity(L) |
18 |
48 |
69 |
| Circulation |
Forced convection |
| Shake Mode |
Convolution |
| Orbit Diameter(mm) |
Φ26 |
| Cyclotron Frequency |
Range (rpm/min) |
0(to do static culture), 40-300 |
0 (to do static culture), 20-300 |
| Resolution (rpm) |
±1 |
| Temperature |
Range (℃) |
RT+5~60 |
RT+5~60 |
10~60 |
RT-15-60 (Ambient temp-15) |
| Fluctuation (℃) |
≤0.1(37℃) |
| Resolution (℃) |
± 0.1 |
| Uniformity (℃) |
± 1(37℃) |
| Size (WxDxH) |
External (mm) |
440x410x390 |
600x580x510 |
832x690x653 |
780x750x570 |
| Internal(mm) |
320x295x190 |
440x405x270 |
480x450x320 |
480x450x320 |
| Flask Clamp |
Max. Capacity |
50mlx12 or 100mlx9 or 250mlx6 |
50mlx20 or 100mlx9 or 250mlx12 or 500mlx9 or 1000mlx4 |
100mlx20 or 250mlx16 or 500mlx9 or 1000mlx5 or 2000mlx4 |
| Standard Capacity |
100mlx9 |
50mlx4 or 100mlx4 or 250mlx3 or 500mlx3 |
50mlx5 or 100mlx5 or 250mlx4 or 500mlx3 |
50mlx5 or 100mlx5 or 250mlx4 or 500mlx3 |
| Controller |
PID Microcomputer |
| Control Mode |
Fixed value mode, static mode |
| Display |
Large high efinition LCD |
| Timer |
1-9999min (or continuous operation) |
| Refrigerant |
/ |
/ |
R134a (CFC free) |
| Defrosting Mode |
/ |
/ |
Automatic |
| Safety Device |
Self-diagnosis; visible & audible over temperaure, abnormal status alarm, leakage protector |
| Electricity |
Voltage/Frequency (V/Hz) |
AC 220/110V, 50/60Hz |
| Consumption (W) |
220 |
320 |
580 |
580 |
| N.W./G.W. (kg) |
31/41 |
72/88 |
81/113 |
81/113 |
| Shipping Size (WxDxH)(mm) |
580x530x540 |
740x700x660 |
900x860x760 |
900x860x760 |
| Optional |
7 inches touch screen, USB data storage download processing system, humidity real-time monitoring, various flask clamps, universal spring clamp |
