Automatic Tissue Embedding Center & Cooling System

Automatic Tissue Embedding Center & Cooling System

This automatic tissue embedding center & cooling system features precise temperature control technology, ensuring the consistent and reliable progression of tissue embedding procedures.

  • Model: TE-III&CS-III
  • Paraffin Chamber Capacity: 5 L
  • Temperature Range (Forceps Holder, Left & Right Thermal Chamber, Paraffin Chamber & Distributor, Working Table): RT-99 ℃
  • Temperature Range (Cold Plate): +5 to -35 ℃
  • Working Area Sizes (Working Table): 150×90 mm
  • Working Area Sizes (Cold Plate): 330×322 mm
  • Small Cooling Plate: YES

Share the product


Warning: call_user_func_array() expects parameter 1 to be a valid callback, function 'wpb_pcf_contact_form_button' not found or invalid function name in /www/wwwroot/www.scitekuae.com/wp-includes/class-wp-hook.php on line 341
分类： 标签：

Tissue Embedding Center & Cooling System Feature:

  1. Fully automatic control with flexible weekly on/off scheduling.
  2. Advanced silicone heating elements deliver fast, uniform, energy-efficient heating.
  3. High-precision U.S. temperature sensing chip ensures stable, accurate monitoring with visual status display.
  4. Independent temperature control for paraffin chamber, dispenser, thermal chamber, and work surface with multi-level overheat protection.
  5. Memory and auto-restart functions retain preset temperatures at startup.
  6. Integrated cooling plate enables rapid tissue freezing during embedding.
  7. Large 5 L paraffin chamber supports high-volume embedding in a single run.
  8. Low-voltage lighting system ensures safe, reliable illumination.
  9. Dual control options via soft-touch button or foot pedal.
  10. Heated workstation and forceps holders improve embedding efficiency.
  11. High-accuracy time display allows easy parameter adjustment.

Tissue Embedding Center & Cooling System Specification:

Model TE-III&CS-III
Paraffin Chamber Capacity 5 L
Temperature Range Forceps Holder RT-99 ℃
Paraffin Chamber
Left Thermal Chamber
Right Thermal Chamber
Working Table
Paraffin Distributor
Cold Plate +5 to -35 ℃
Small Cooling Plate ＜ -5 ℃
Temperature Control Precision ± 1℃
Paraffin Flow Control Automatic soft-touch switch, foot-operated switch
Fully Programmable ON/OFF Control Allows automatic system start and stop anytime weekly
Safety Protection Double overheat protection device
Automatic Memory Recovery Function Yes
Working Area Size Thermal Chamber 240×160×55 mm
Working Table 150×90 mm
Small Cooling Plate 60×50 mm
Cold Plate 330×322 mm
Power Supply AC 220 V ± 10%, 50 Hz (standard model);

AC 110 V ± 10%, 60 Hz
Power 800 W (TE-III)
300 W (CS-III)
Dimensions Size (W×D×H) 650×580×450 mm (TE-III)
650×380×450 mm (CS-III)
Shipping Size (W×D×H) 770×690×610 mm (TE-III )
800×480×580 mm (CS-III)
N.W. /G.W. 40/45 kg (TE-III)
29/36 kg (CS-III)
