Automatic Tissue Embedding Center & Cooling System

Automatic Tissue Embedding Center & Cooling System

This automatic tissue embedding center & cooling system features precise temperature control technology which ensures the consistent and reliable progression of tissue embedding procedures. It provides clear and real-time visual feedback on operational status by equipped with LED indicators.

  • Model: TE-I&CS-I
  • Paraffin Chamber Capacity: 3 L
  • Temperature Range (Forceps Holder, Left & Right Thermal Chamber, Paraffin Chamber & Distributor, Working Table): 55-75 ℃
  • Temperature Range (Cold Plate): -20 to -30 ℃
  • Working Area Sizes (Working Table): 180×120 mm
  • Working Area Sizes (Cold Plate): 320×300 mm

Share the product


Warning: call_user_func_array() expects parameter 1 to be a valid callback, function 'wpb_pcf_contact_form_button' not found or invalid function name in /www/wwwroot/www.scitekuae.com/wp-includes/class-wp-hook.php on line 341
分类： 标签：

Tissue Embedding Center & Cooling Syste Feature:

  1. Fully computerized control with weekly programmable start scheduling.
  2. Advanced U.S. microprocessor with five independent PID temperature zones.
  3. Clean control panel with blue function LEDs and color-changing temperature indicators.
  4. Flexible heating technology enables fast, uniform heating with high precision.
  5. Dual over-temperature protection ensures safe, reliable operation.
  6. Memory and auto-reset functions retain temperature settings automatically.
  7. Modular split design allows flexible pairing of embedding center and cooling system.
  8. Dual front and rear switches on the cooling unit enhance usability and safety.
  9. Adjustable inlet valve controls paraffin nozzle flow for diverse embedding needs.
  10. Dual paraffin dispensing via soft-touch control or foot switch for convenience.
  11. Large granite work surface improves durability, aesthetics, and easy paraffin cleanup

Tissue Embedding Center & Cooling Syste Specification:

Model TE-I&CS-I
Paraffin Chamber Capacity 3 L
Temperature Range Forceps Holder 55-75 ℃
Paraffin Chamber
Left Thermal Chamber
Right Thermal Chamber
Working Table
Paraffin Distributor
Cold Plate -20 to -30 ℃
Small Cooling Plate /
Temperature Control Precision ± 1 ℃
Paraffin Flow Control Automatic soft-touch switch, foot-operated switch
Fully Programmable ON/OFF Control Allows automatic system start and stop anytime weekly
Safety Protection Double overheat protection device
Automatic Memory Recovery Function Yes
Working Area Size Thermal Chamber 225×145×55 mm
Working Table 180×120 mm
Cold Plate 320×300 mm
Small Cooling Plate /
Power Supply AC 220 V±10% 50 Hz (standard model);

AC 110 V±10% 60 Hz
Power 650 W（TE-I）
300 W（CS-I）
Dimensions Size (W×D×H) 550×525×385 mm (TE-I)
345×590×385 mm (CS-I)
Shipping Size (W×D×H) 670×630×520 mm (TE-I)
700×450×530 mm (CS-I)
N.W./G.W. 30/41 kg (TE-I)
29/37 kg (CS-I)
